Barcode Ratio Width to Thin
Parameter
P6
P 6
0
1
2
3
Note: Code 93, MSI 10/10, Code 128 are fixed 2.0 to 1
Best results for Code 39, 2 of 5 industrial, 2 of 5 interleaved and Codabar with 2.5 to 1
Barcode Printing Direction
Parameter
Uni-directional or bi-directional
P7
printing
Start Position of Barcode Printing
The start position for barcode printing is the current print position. For both horizontal and vertical printing,
the print position after printing barcodes is the same line as the start position next to the barcode printed.
Description
Ratio Width to Thin
Code 39
2 of 5 industrial
2 of 5 interleaved
Codabar
Code 93
MSI mod 10/10
Code 128
2.0 to 1
2.5 to 1
3.0 to 1
3.5 to 1
Description
• default: 0 (2 to 1))
values are:
0 or not programmed means no changes
1 uni-directional printing in LQ
2 bi-directional printing in LQ
3 uni-directional printing in NLQ
4 bi-directional printing in NLQ
Function
EAN 8
EAN 13
UPC-A
UPC-E
SC3
SC6
SC9
SC3
Function
Appendix F-6
