Escape Sequenz
ESC ( - P1 P2 P3 P4 P5
ESC <
ESC : NUL P1 NUL
ESC & NUL P1 P2 P3 P4 P5 v1 .. vn
Notes:
This Command defines one or more characters in a RAM character table.
All User Defined Characters are erased when the printer is switched off.
Set the Interface Buffer to 1k or 8K (max 50 defined char in LQ, 128 in draft), or use a RAM card for up
to 128 User Defined Characters in LQ. Set maximum every second dot to "1" in a horizontal line! User
Defined Characters can be defined in four different print modes:resolution (vertical x horizontal)
Normal Size with Draft:
Normal Size with LQ / proport.:
Sub-/ Superscript with Draft:
with LQ/proport.
The characters can only be activated in the same mode as defined. The character layout is coded in three
bytes (24 bit vertical) or two bytes (16 bit vertical) per column, top to bottom.
To print the character change to the User Defined Character Set with ESC %
Example: vertical box, normal size with draft at code table position "41" (P3=8, P4=5, P5=8)
hex: 1B 26 00 41 41 08 05 08 FF FF FF 00 00 00 80 00 01 00 00 00 FF FF FF
Mnemonic Function
Select Line Marking
P1 = 0/3 (fixed value)
P2 = 0/0 (fixed value)
P3 = 0/1 (fixed alue)
P4 = 0/1 : underline
P4 = 0/2 : strike through
P4 = 0/3 : overscore
P5 = 0/0 : cancel score line selected by P4
P5 = 0/1 : single continuous line
P5 = 0/2 : double continuous line
P5 = 0/5 : single broken line
P5 = 0/6 : double broken line
Select Unidirectional Mode (one line)
Copy ROM Character Set to RAM
P1 = 0/0 : ROMAN
P1 = 0/1 : SANS SERIF
P1 = 0/2 : COURIER
P1 = 0/3 : PRESTIGE
P1 = 0/4 : SCRIPT
P1 = 0/5 : OCR-B
P1 = 0/6 : OCR-A
P1 = 0/7 : ORATOR-C
P1 = 0/8 : ORATO
Define User Defined Characters
P1 = first code table position (P1 = 0/0...P2)
P2 = last code table position (P2 = P1...7/F)
P3 = front space
P4 = body length
P5 = rear space
v1 .. vn = binary data in hex (vn = 0/0...F/F)
24 x 15
24 x 37
16 x 15 Sub-/ Superscript
16 x 37
R
(P3 = 0/0...5/0)
Draft: (P4 = 0/0...0/F)
LQ:
(P4 = 0/0...2/5)
(P5 = 0/0...5/0)
Appendix E-6
