Vertical Form Handling
The printer is always equipped with two continuous form tractors. The last sheet of a continuous
form stack can be printed on up to the end of the form.
The capabillity of the printer to feed paper from different sources is optimally supplemented by the
option that automatically adjust the distance between the print head and the print bar.
Table 4: Vertical Form Handling
Escape Sequenz
ESC 0
ESC 2
ESC 3 P1
ESC + P1
ESC A P1
ESC B NUL
ESC B P1 P2 . . P16 NUL
ESC C P1
ESC C NUL P1
ESC J P1
ESC N P
ESC O
ESC b P1 P2 .. P16 NUL
ESC b P1 NUL
ESC j P1
ESC / P1
ESC EM P1
Function
Set Line Space to 1/8"
Set Line Space to 1/6"
Set Line Space to P1/180"
Set Line Space to P1/360"
Set Line Space to P1/60"
Clear Vertical Tabs
Set Vertical Tabs
Set Form Length in Lines
Set Form Length in Inches
Perform P1/180" Line Feed
Set Automatic Perforation Skip
P1 is the number of lines from bottom of paper to skip.
Cancel Automatic Perforation Skip
Set Vertical Tabs in Channel P1
P1 = 0/0 .. 0/7 : channel 0 - 7
P2..P16 = line number
Clear all Tabs in Channel
P1 P1 = 0/0 .. 0/7 : channel 0 - 7
P1
„Reverse Line Feed
Perform /
180
Select Vertical Tab Channel
P1 = 0/0 .. 0/7 : channel 0 .. 7
Form Feed and ASF Control Form Feed: EM = 1/9
ASF Control:
P1 = 3/1: ASF Bin 1 or Bin 2
P1 = 3/2: ASF Bin 2 or Bin 3
P1 = 3/3: ASF Bin1 or Bin 2 or Bin 3
P1 = R: (5/2) eject sheet
(P1 =0/ 0...F/F)
(P1 = 0/0...F/F)
(P1 = 0/0...7/F)
(P1...P16 = 0/1...F/F)
(P1 = 0/1...7/F)
(P1 = 0/1...1/6)
(P1 = 0/0...F/F)
(P1 = 0/1...7/F)
(P2..P16 = 0/1..F/F
)
(P1 = 0/0...F/F)
Appendix E-3
