Temperature; Recorder; Specific Features; Alternating Measurements - Consort C832 Anleitung

1. Press SET until the display shows [SEt °C]. Select the desired mode and press
CAL.
2. The display will show the measured temperature e.g. [°C=23.7][Aut]. If neces-
sary, calibrate your probe and press CAL. Press RES to reset the temperature
calibration to the original factory calibration.
3. When no Pt1000 temperature probe is connected to the instrument the display
will show the manual temperature e.g. [°C=23.7][MAn]. Shift to the proper
temperature and press CAL.
1. Press SET until the display shows [SEt rEC] and press CAL.
2. The display shows for all channels e.g. [rEc=PH1], [rEc=MV2], [rEc=Cn1],
[rEc=Cn2], [rEc=EC], [rEc=dPH], [rEc=MG.L], [rEc=%], [rEc=°C]...etc. Select
the desired mode and press CAL.
3. This step is skipped unless [rEc=EC] has been chosen. Press CAL and the display
shows the conductivity measuring range and units, e.g. [rEc 0.01mS][Unit].
Select the desired range and press CAL.
4. The display shows e.g. [rEc=6.00][LoW]. Select the desired minimum level
corresponding to a 0 V recorder output and press CAL.
5. The display shows e.g. [rEc=8.00][HiGH]. Select the desired maximum level
corresponding to a 2 V recorder output and press CAL. The display shows [SEt
rEc].
1. Press SET until the display shows [SEtUP] and press CAL.
2. The display lets you choose between [bEEP on] or [bEEP OFF]. Decide whether
or not the beeper should sound each time the keyboard is touched and press
CAL.
3. The display lets you choose between [POWEr][on] or [POWEr][OFF]. Choose
[POWEr][on] to inactivate the ON/OFF-key (meter is always on and cannot be
switched off). After an interruption of the mains power, the meter will resume
measurements automatically. Choose [POWEr][OFF] to activate the ON/OFF-
key (meter can be switched on or off). Press CAL.
4. The display shows e.g. [br=2400]. Pre-set the desired baud-rate (300...9600
b/s) and press CAL.
5. The display shows e.g. [rS=120]. Select the desired time interval (0...9999 s)
between the transmitted data (RS232). Pre-set to zero if no automatic printing
is required and press CAL.
6. The display shows e.g. [Id.no=5]. Select the desired identification number
(0...999) for your meter and press CAL. The instrument can be identified by
e.g. a computer when a specific number is allocated to it. Pre-set to zero to
ignore this number.
7. The display shows [Code on], [Code OFF] or [Code CAL]. Decide whether all
future access to the instrument should be by entering a code (on) or not (off).
Press CAL. Select [Code CAL] to enter your personal code to avoid undesired
access to the instrument. The display shows [E=-----] while [=] is blinking.
Enter your secret sequence of 5 keys to proceed. Press CAL.
1. Press SET until the display shows [ALt] and press MODE to start the alternating
mode. The display alternates between the selected modes with an interval of
4 s. Pressing PRINT in this mode will print all values of the selected chan-
nels.
2. Press MODE again to stop this mode and continue with the actual channel.
C831 • C832 • C833 • C835 • C838

Temperature

Recorder

Specific features

Alternating measurements

9 / 74
