1. Select the TDS range (mg/l) or the salinity range (SAL) by pressing MODE. The
display will immediately show the measured value according to the previous
calibration. Should you want to recalibrate, press CAL. Proceed as for conduc-
tivity.
1. Select the oxygen range (mg/l O
ately show the measured value according to the previous calibration. Should
you want to recalibrate, press CAL.
2. The display shows the air pressure correction and the salinity correction.
Select the proper values and press CAL. Leave salinity correction to zero unless
you are going to measure in heavily salted solutions such as e.g. sea-water (35
g/l). Select [CALIBRATE], press CAL and follow the instructions on the screen
until the calibration is finished.
3. The electrode exposed to the air reaches an equilibrium corresponding to the
partial pressure of oxygen and thus to saturation in water at the given temper-
ature. The instrument shows the measured saturation, current, temperature,
and will calibrate automatically when readings are stable.
4. After rinsing the electrodes with distilled water, immerse them in the samples
and read the display. Stirring the solution during the measurements promotes
the homogeneity and is obligatory! The advection rate must be at least 10
cm/s.
5. Rinse the electrode always after use and store it in distilled water.
1. Read temperature by pressing MODE. Without Pt1000, adjust the manual tem-
perature compensation and proceed by pressing MODE. Should you want to
recalibrate, press CAL.
2. Immerse the Pt1000 in a standard solution of known temperature (not C532).
Select [CALIBRATE] and press CAL. Calibrate to the proper value and press CAL
again or press MODE to reset the factory settings.
1. Press ê to store the displayed value in memory. The display shows [log#?] and
a next storage address (1...200).
2. Select the desired address and press CAL to enter the measured value in
memory.
1. Press é to recall the stored data. The display shows a list of stored values.
2. Select the desired address to read the stored values.
3. Press MODE to return to the normal measurements.
1. Select the set-up menu by pressing MODE.
2. Follow the instructions on the screen to adjust language, contrast and automa-
tic power-off timer. Press each time CAL to confirm or MODE to exit.
1. Select the desired range by pressing MODE.
2. Press CAL, select GLP and press CAL to display a complete calibration report.
C53x èwww.consort.be
) by pressing MODE. The display will immedi-
2

TDS/Salinity measurement

(C533, C535)

Oxygen measurement

(C534, C535)

Temperature measurement

Logging data

(C533, C534, C535)

Recalling data

(C533, C534, C535)

Set-up

GLP

5
