12.2 Technical Data

Operating temperature
Storage temperature
Charging temperature
Relative humidity
Joint module weight
Carbon spring element weight
Glass fibre spring element weight
Maximum flexion angle
Maximum patient weight with carbon spring
element (17CF2=1)
Maximum patient weight with glass fibre spring
element (17CF2=4)
Minimum patient weight
Protection class (battery charger)
Battery charger operating voltage
Supply voltage
Mains frequency
56 | Ottobock
-10 °C to 60 °C / 14 °F to 140 °F
-10 °C to 60 °C / 14 °F to 140 °F
0 °C to 50 °C / 32 °F to 122 °F
Max. 80 % relative humidity, non-condensing
Approx. 1400 g / 49.4 oz
Approx. 115 g / 4.06 oz
Approx. 145 g / 5.11 oz
120°(depending on the design)
125 kg / 275 lbs
100 kg / 220 lbs
Approx. 45 kg / 100 lbs
IP44
12 V DC
100 V - 260 V AC
50 Hz - 60 Hz
