→ For the "low damping" setting in empty battery mode, the user must have the necessary
muscular and cognitive abilities to control a freely moving knee joint without stance phase
control.
→ From empty battery mode, operating mode (1st mode) can be reactivated by charging the
orthosis.
The damping value activated in empty battery mode can be configured by the Orthotist. Damping
can be high (stance phase damping value) or low (cycling mode).

7.5 Storage and Bleeding Air

Air may accumulate in the hydraulic unit if the orthosis is stored for longer periods and not in an
upright position. This is noticeable through sounds and irregular damping behaviour.
The automatic ventilation mechanism ensures that all functions of the orthosis are again fully avail­
able after approximately 10 - 20 steps.
Replacement is not required in this case.

7.6 Operating States/Error Signals

The orthosis joint module indicates operating states and error messages with beep signals.

7.6.1 Safety Mode Activation Indicator

Beep signal
1x short at intervals of approx.
1 second
4x short then pause, duration
30 seconds
1x short, interval 5 seconds,
duration 10 minutes
Ongoing short beep signal
Continuous beep signal
Error
Overheating
Critical device error
Critical device error
Highly critical device
error
Correction
Cease normal use of the orthosis
immediately and check whether
stance phase control is active.
Do not resume using the orthosis
until the joint module has cooled
down and the orthosis no longer
emits the warning.
Cease normal use of the orthosis
immediately and check whether
stance phase control is active.
The entire orthosis must be sent to
the authorised Ottobock Service
Centre for inspection or repair. Your
CPO is the contact person.
Cease normal use of the orthosis
immediately and check whether
stance phase control is active.
This error signal can be deactivated
by connecting the battery charger.
If this error signal occurs again, the
entire orthosis must be sent to the
authorised Ottobock Service Centre
for inspection or repair. Your CPO is
the contact person.
Cease normal use of the orthosis
immediately and check whether
stance phase control is active.
The entire orthosis must be sent to
the authorised Ottobock Service
Centre for inspection or repair. Your
CPO is the contact person.
