7.3 Mode Switching

INFORMATION
Before the first step, always verify whether the desired mode corresponds to the respective
movement type.
Activating 1st mode:
INFORMATION
Regardless of the mode selected before switching, this process always switches to 1st mode.
1) Push and hold button 1.
→ A long beep signal is emitted.
2) Take the weight off the orthosis.
→ A short beep signal is emitted.
→ The orthosis has successful switched to 1st mode.
Activating 2nd mode:
INFORMATION
Regardless of the mode selected before switching, this process always switches to 2nd mode.
1) Push and hold button 2.
→ A long beep signal is emitted.
2) Take the weight off the orthosis.
→ Two short beep signals are emitted.
→ The orthosis has successfully switched to 2nd mode.
Activating LOM mode:
From 1st mode to LOM mode:
► Briefly push button 2 twice.
→ Three short beep signals are emitted.
→ The orthosis has successfully switched to LOM mode.
From 2nd mode to LOM mode:
1) Briefly push button 2 twice.
→ A long beep signal is emitted.
50 | Ottobock
1. Upper button, button 1 – return to 1st mode
2. Lower button, button 2 – switching to 2nd and LOM mode
INFORMATION: With the exception of 1st mode, some movement pat­
terns are limited or not possible in all other modes.
