3.4 Specifying the IP address

Open the SETTINGS tab, and under CATEGORIES select Local Area Network on the left to modify the IP settings.
A user with name „admin" and password „ceag" has been factory set for access to setting options of the
router via the web interface. Please modify the password immediately following initial start-up.
You can now enter the desired values in the fields IP Address, Subnet Mask, Gateway, DNS
natively, you can specify the referencing of dynamic IP address data via the DHCP check box. Settings are
saved by clicking the Save button.
With the static IP setting the specifications for the gateway and DNS server can remain empty. These are needed
though when external NTP servers should be used or when remote maintenance is planned.
Consider that modifying the IP address of the router invalidates the existing connection to the web interface,
meaning this must then be reestablished. If switching to DHCP has been implemented, then the IP address of the
router must first be determined (e.g. via the IP router or the DeviceFinder).
We recommend not to use dynamic IP addresses for the router because routing is interrupted for a period of time
with each address modification. This can be prevented by setting the DHCP server so that it always assigns the
same DHCP lease with the same IP address to the CG-S / IP-Router+ 1P.
Figure: IP settings
5 Several DNS server addresses can also be entered, separated by commas.
6 TTL, Time to live, is a validation period that can be assigned to data in the IP network. This is specified in
seconds. The maximum value is 255.
and TTL . Alter
5 6
