All participants in a LON/IP channel should use the same multicast address and the same port number.
Channel timeout:
Delayed IP packets are identified with the Channel Timeout. If a value is specified here, all
devices in the network must have exactly the same time. The value is specified in
milliseconds between 1 and 1500.
The 0 default setting means that this monitoring is deactivated.
MD5 Shared Secret: This field contains the key in case a MD5 authentication should be used. If the field remains
empty, authentication is deactivated. If authentication is used, check whether all devices
support this.
NTP server: Time consistency is important with network operation. This is why use of an NTP server is
recommended. The CG-S / IP Router+ 1P can itself be configured as one. (see section 3.5).
We recommend making the configuration server the NTP server. This ensures synchronous
time and not all devices have to reference the time from the internet.
If NTP servers are to be used their IP addresses must be specified here. This is also requi
red if the internal NTP server of the device is to be used. The standard NTP port is 123.
Global Cycle Time: Time interval in seconds in which the LON/IP devices are queried to check their existence.
(Default = 60). Cyclic checking is deactivated with the value 0.

4.2 Managing the router via configuration server

If the CG-S / IP Router+ 1P is operated as a configuration server, then access to the clients is also possible from
this device if it is a CG-S / IP Router+ or a device with a web interface. Access the functions for this via the SET-
TINGS tab under CATEGORIES CEA-852 Channel List.
