4. Configuration server

The CG-S / IP Router+ 1P has an integrated configuration server which can be activated via the web interface. This
manages information for CG-S / IP-Router and CG-S / IP interface.

4.1 Setting up the configuration server

Activation of the configuration server on the CG-S / IP-Router+ 1P is via its web interface. Enter the IP address of
the corresponding router into the address bar of a web browser on a PC that is connected to the router. Click on the
SETTINGS tab, and select CEA-852 server under CATEGORIES.
Only a single configuration server may be operated in a LON/IP channel.
Figure: Configuration server settings
The configuration server is activated by ticking the corresponding checkbox.

Automatic registration:

IP Unicast Port:
If this value is modified this has to be set identically for all devices on the LON/IP channel.
Settings for unicast and multicast addresses on the configuration server overwrite the settings on individual devices.
IP Multicast address and port: LON packets can be sent in parallel on the LON/IP channel to several recipients
42
If this mode is selected, LON/IP reporting with the configuration server are
registered. These are automatically deleted again though if they do not register
automatically within the Automatic Deregistration Timeout. the time interval
is specified in seconds (default = 0s).
This is the port via which the configuration server is reached (default = 1629,
according to CEA-852 standard ).
via the IP multicast addressing. This contributes significantly to reduction of
network load. Multicast addressing is recommended especially when no channel
routing is possible.
