and are still subject to the Automatic Deregistration Timeout.
Devices can thus be excluded from the system with the Blacklist command. The IP channel of a device can be tem-
porarily locked for the complete system, for example for testing purposes, with Disable.

5. Using router functionality

5.1 Configuring the LON/IP interface

Configuration of the CEA-852 interface is via the web interface of the CG-S / IP Router+ 1P. Enter the IP address
of the router into the address bar of a web browser on a PC that is connected to the router. Click on the SETTINGS
tab, and select CEA-852 Device under CATEGORIES.
Figure: CEA-852 settings
