10. Trouble shooting
RC-System
RC-System does not function
Range of transmitter too small
Servos do not respond correctly
RC-System functions incorrectly,
while the engine is running
Engine or fuel system
The engine does not start
Engine does not get fuel
Engine starts, but stops again
106
Batteries/rechargeable batteries of transmitter and/or receiver
are empty
Batteries/rechargeable batteries are inserted incorrectly
Plug of batteries/rechargeable batteries of receiver is loose
Batteries/rechargeable batteries of transmitter and/or receiver
are weak
Receiving power of the antenna is too low
The antenna of the transmitter is not pulled out
The antenna of the receiver is not pulled out on its full length
The antenna of the receiver is cut
Batteries/rechargeable batteries of transmitter and/or receiver
are weak
Toothed wheels in servo links do not engage or are defective
Adjusting rings on the servo motor are loose
Servo Reverse Switch was set on „REV" accidentally
Crystal of receiver is loose
Plug of batteries/rechargeable batteries of receiver is loose
Receiver damaged, e.g. after a crash
Defective glow plug or empty start battery
Start battery defective
Fuel tank is empty or carburettor is not filled
Carburettor not correctly set
Fuel is old or dirty
Combustion room full with fuel (flooded)
additional air is sucked via fuel line or engine
Servo links not properly adjusted
Fuel line, air filter or exhaust blocked
Main nozzle needle fully turned in
Idle speed mix too lean
Fuel hoses bent
Fuel tank defective
Fuel tank is empty
Fuel line, air filter or exhaust blocked
Carburettor not correctly set
Engine overheats
Replace the batteries/rechargeable batteries of transmitter
and/or receiver
Check the polarity of the batteries/rechargeable batteries
Firmly insert the plug again
Replace the batteries/rechargeable batteries of transmitter
and/or receiver
Pull out the antenna of the transmitter completely Completely
unwind the antenna of the receiver and guide it upwards
Pull out the antenna completely
Pull out the wire of the antenna completely.
Repair the receiver
Replace the batteries/rechargeable batteries of transmitter
and/or receiver
Repair the servo
Readjust the adjusting rings; use factory settings
Switch the Servo Reverse onto „NORM"
Reinsert receiver crystal
Firmly insert the plug again
Repair the receiver
Replace glow plug, Charge start battery
Replace start battery
Fill the fuel tank and pump fuel with the rotor starter to the
carburettor
Reset idle speed and main nozzle needle
Replace fuel and check fuel filter
Unscrew glow plug and proceed as described in the cor-
responding chapter
Check/replace fuel hoses and/or tighten all engine screws
Place servo in neutral position and readjust
Clean blocked parts, if necessary, replace
Readjust the main nozzle needle according to factory
setting
Readjust the idle speed mix adjusting screw to factory
setting
Check and straighten fuel hoses
Replace fuel tank
Fill fuel tank
Clean blocked parts, if necessary, replace
Reset idle speed and main nozzle needle
Check the temperature. Above 150°, the fuel mix must be
enriched. Check if the wheels can move freely.
