Switch-Off Delay - Busch-Jaeger Busch-Wächter Präsenz tech 6813-101 Betriebsanleitung

Mode of Operation GB

5.4 Switch-off Delay

The function "switch-off delay" is defined by the lens system and the "Time" potentiometer.
30
10
Short-time impulse : e.g., to control automatic switching of
sec
20
1
staircase lighting.
15
min
10
5
Via the lens system, the Presence Detector determines whether there is movement in the
room. The setting on the "Time" potentiometer defines how long the lighting remains
switched on after the last movement has been detected.
The switch-off delay is reset to the selected time value (e.g., 7 min.) after each new
movement is detected. If no new movement is registered in the room until this time has
expired, the lighting is switched off.
98
