Mode of Operation

5.3 Brightness Limit Value

This function is defined by the brightness sensor, the lens system and the "Lux" potentiometer.
The integrated light sensor continuously measures the brightness reflected on the ceiling
and compares this brightness value with the limit value set on the Presence Detector
(selectable from 5 to 1000 Lux).
NOTE
The Lux value set* refers to the brightness reflected at the Presence Detector and not
to the brightness prevailing at the workplace. As a rule, the Lux value registered by the
Presence Detector is distinctly lower than the Lux value prevailing at the workplace.
Example:
*approx. 50 Lux
5
*approx. 150 Lux
1000
*approx. 250 Lux
100
500
Deactivation of brightness measurement:
> corridor area:
> office workplace:
> laboratory workplace:
approx. 150 Lux
approx. 400 Lux
approx. 650 Lux
