Fault Possible cause
Plant is not run- Mains fuse have got triggered
ning
No pressure Amount of water supply is too low.
build-up in the
Pipe is blocked
plant or pump is
System is sucking air
knocking
Only HDS-C 7/11, HDS-C 9/15: Heating
coil has heavy calcium deposits
Pump leaky Defective pump part
(more than 3
drops of water
per minute)
Detergent is not Filter or hose is blocked
taken in
Backflow valve stuck
Solenoid valve is defective
High pressure Detergent container is empty
pump is sucking
in air.
Only HDS-C 7/ Washing programme with hot water not se-
11, HDS-C 9/15: lected.
Burner does not
Water shortage
ignite or the flame
glows off during
Fuel filter dirty
operation
No ignition
Too low water Temperature has been set too low.
temperature for
Nozzle in spray pipe is rinsed out.
hot water opera-
tions
Only HDS-C 7/11, HDS-C 9/15: Heating
coil has heavy calcium deposits
Only HDS-C 7/11, HDS-C 9/15: Heating
coil sooted

Accessories

Attachment sets
Sticker Operating Instructions
German,Order.-Nr.: 5.391-558.0
English, Order no.: 5.391-559.0
French, Order no.: 5.391-560.0
Italian, Order no.: 5.391-561.0
Spanish, Order no.: 5.391-562.0
Portuguese, Order no.: 5.391-563.0
Dutch, Order no.: 5.391-564.0
Greek, Order no.: 5.391-565.0
Polish, Order no.: 5.391-566.0
Water filter G 1"
Best.-Nr.: 6.414-278.0
Lance holder
Best.-Nr.:2.641-310.0
Hose switch
Best.-Nr.: 2.641-320.0
Coin acceptor
Best.-Nr.: 2.641-297.0
Coin counter
Best.-Nr.: 2.641-333.0
Faults without display
Remedy
Check mains fuses and mains voltage
Check water supply level (refer to technical data).
Check all pipes to see that there are no blockages
Check system for leaks, the detergent suction hoses
must lie in the detergent, refill detergent container.
Softening using RM 110 is not working. Rectify
cause, decalcify the plant.
Replace defective part.
Clean the parts.
Remove suction hose from pump head and loosen
the recoil valve using a blunt object.
Replace valve.
Refill detergent.
Select another washing programme.
Check water supply, check connections, clean water
shortage safeguard.
Change fuel filter.
Check ignition.
Check ignition electrodes.
Set the thermostat to a higher level.
Define the quantity to be transported by the pump.
Replace nozzle if the specifications given in the tech-
nical data are exceeded with a large margin.
Softening using RM 110 is not working. Rectify
cause, decalcify the plant.
Remove the soot from the heating coil.
Fuel
Engine oil Hypoid SAE 90
Order no. : 6.288-020.0
Engine oil 15W40
Order no. 6.288-050.0
Silicon grease
Order no. : 6.288-072.0
Lock grease
Order no. : 6.288-116.0
Steel care product
Order no. : 6.290-911.0
Softener liquid RM 110
For softening
Detergent
Warning!
Before using the cleaning agent, please re-
fer to the notice on the package. Do not use
the following cleaning agents:
cleaning agent containing nitrit acid
–
cleaning agent containing active chlo-
–
rinate
11
-
EN
If you use such cleaning agents, it will dam-
age your equipment.
RM 806 ASF, 1+3
HDS-C 9/15
HDS-C 7/11
HDS-C 8/15-E
Lime solvent
RM 100 ASF
RM 101 ASF

Warranty

The warranty terms published by our com-
petent sales company are applicable in
each country. We will repair potential fail-
ures of your appliance within the warranty
period free of charge, provided that such
failure is caused by faulty material or de-
fects in fabrication. In the event of a warran-
ty claim please contact your dealer or the
nearest authorized Customer Service cent-
er. Please submit the proof of purchase.
By whom
Operator
Operator
Operator
Operator
Operator,
Customer
Service
Customer
Service
Operator
Operator
Customer
Service
Operator
Operator
Operator
Operator
Customer
Service
Customer
Service
Operator
Operator
Customer
Service
Customer
Service
Dosing ml/
min
120...150
98...120
110...135
27
