1 Documentation
There are further relevant documents - see the list in the original installa-
tion instructions.
These documents can also be downloaded at
com/p/msa501".

2 Safety information

Safety information of original installation instruction apply.

3 Config Input

The meaning of these inputs is shown in the table below:

Config

GND
+UB (while enco-
der supply is being
turned on)
+UB
GND
3.1 Config
If the "Config" input remains unused, it shall be connected to GND for rea-
NOTICE
sons of interference avoidance!
The "Config" input has two functions:
1. If the sensor is in the SSI mode, the position value of the sensor can
2. If the Config input is on +UB during turning on of sensor supply, the
MSA501-S(SSI) · Date 06.06.2016 · Art. No. 85615 · Mod. status 152/16
Encoder function
The sensor is in the SSI mode.
The sensor is in the boot loader mode for the first
10 s (installing new firmware enabled), then it
changes over to the service mode.
Setting of the position value to the calibration value
(only if the sensor is in the SSI mode).
min. 1.2 s
be set to the calibration value by setting this input to +UB. The signal
must be applied to the Config input for at least approx. 1.2 s in order
to avoid erroneous activation of this function by short-time interfe-
rence signals.
sensor will first change over from the SSI mode to the so-called boot
loader mode for 10 s. Now, the sensor can be programmed with a new
firmware. Only competent professionals should carry out this type of
programming! Upon termination of the boot loader mode, the encoder
will be in the service mode. The sensor can be parameterized and que-
ried for status information via the RS485 data interface which has now
turned bidirectional (D+, D-), (see chapter 9.2).
