120 Signal type
Selects the signal for the analogue output in Volt
0 to 10 V (Default)
121 Lower limit
Analogue output Volt lower limit range
-32767 to +32767 [Digit
122 Upper limit
Analogue output Volt upper limit range
-32767 to +32767 [Digit
123 Error value
Selects the value of the analogue output in Volt in case of error
0 V (Default)
10 V

11.11 Comunication port

Parameters to configure the serial communication port.
126 Slave address
Selects the slave address for serial communication
1 to 254. Default: 240
127 Baud rate
Selects the baud rate for serial communication
1.200 baud
2.400 baud
4.800 baud
9.600 baud
2
The decimal point visualization depends on the "Sensor type" and "Decimal point"
selection.
94
UA964801 - User manual
] (degrees.tenths for temperature sensors), Default: 0
2
2
] (degrees.tenths for temperature sensors) Default: 1000
