AN1 analogue imput
AI1
Shield/Schermo
AI1
White/Bianco
Red/Rosso
Red/Rosso
Shield/Schermo
AI1
Shield/Schermo
V/I
+24Vdc
58
UA964801 - User manual
For thermocouples K, S, R, J, T, E, N, B.
• Comply with polarity.
13
• For possible extensions, use a compensated wire
TC
and terminals suitable for the thermocouples used
(compensated).
14
• When shielded cable is used, it should be grounded at one
side only.
For thermoresistances PT100, NI100.
• For the three-wire connection use wires with the same
section.
• For the two-wire connection short-circuit terminals 14 and
13
15.
• When shielded cable is used, it should be grounded at
14
one side only.
15
13
Weiß/White
14
Rot/Red
15
Rot/Red
For thermoresistances NTC, PTC, PT500, PT1000 and
14
linear potentiometers.
When shielded cable is used, it should be grounded at
15
one side only to avoid ground loop currents.
13
For linear signals V / mA.
• Comply with polarity.
14
• When shielded cable is used, it should be grounded at one
side only.
