6 Offset calibration
Value added / subtracted to the process visualization (usually correcting the
value of environmental temperature)
-1000 to +1000 [Digit
-100.0 to +100.0 (degrees.tenths for temperature sensors). Default 0.0.
7 Gain calibration
Percentage value that is multiplied for the process value (allows to calibrated
the working point)
-100.0% to +100.0%, Default: 0.0
ex: to correct the range from 0 to 1000°C showing 0 to 1010°C, set the parameter to +1.0.
8 Latch On
Automatic setting of limits for linear inputs and potentiometers
Disabled (Default)
Enabled
Setting
9 Totalizer
Visualizes the total "fluid" volume considering the sensor signal as unit/time
value (ex. if the connected sensor has an output 4 to 20mA with F.s. 2000m³/
hour, the parameter 9 Totalizer has to be selected as "Hour" and the display
will visualize the total fluid volume from the last RESET/START signal).
Disabled
Second
Minute
Hour
10 Sum function
Enables the sum function and its dedicated page. Allows to sum the process
value to a variable .
Disabled (Default)
Enabled
78
UA964801 - User manual
] for linear sensors and potentiometers.
2
Display visualizes the process (Default)
Display visualizes the flow in unit/s
Display visualizes the flow in unit/min
Display visualizes the flow in unit/hour
