Sum total
Sum reset
Config. lock
96 Contact type
Selects the digital input 1
Normally open
Normally closed Executes function with open contact

11.7 Digital input 2

Parameters to configure the digital input 2.
100 Input function
Selects the digital input 2 function
Disabled (Default)
Run
Hold
Tare zero (AI)
Alarm reset
Totalizer reset
Peaks reset
Sum total
Sum reset
Config. lock
101 Contact type
Selects the digital input 2 inactive contact.
Normally open
Normally closed Executes function with open contact
(impulse functioning)
(impulse functioning)
inactive contact.
(Default) Executes function with closed contact
(impulse functioning)
(impulse functioning)
(impulse functioning)
(impulse functioning)
(Default) Executes function with closed contact
User manual - UA964801
91
