70 Contact type
Selects the alarm 2 output contact and intervention type
Normally open (Default)
Normally closed
N.O. - Dis pwr on
N.C. - Dis pwr on
71 Alarm threshold
Selects the alarm 2 setpoint
-32767 to +32767 [Digit
72 Deviation threshold
Selects the deviation from alarm 2 setpoint for the band alarm
0 to +32767 [Digit
73 Hysteresis
Alarm 2 hysteresis
-1000 to +1000 [Digit
74 Reset type
Alarm 2 contact reset type
Automatic
Manual
Manual stored
75 Error contact
State of contact for alarm 2 output in case of error
Open (Default)
Closed
] (degrees.tenths for temperature sensors), Default: 0.0.
2
] (degrees.tenths for temperature sensors), Default: 0.0.
2
] (degrees.tenths for temperature sensors), Default: 0.0.
2
(Default)
Manual reset by keyboard
Keeps relay status also after an eventual power failure
