Table of configuration parameters

The following table includes all parameters. Some of them will not be visible on
the models which are not provided with relevant Hardware data.

11.1 Analogue input

Parameters to configure the analogue input.
1 Sensor type
Analogue input configuration/sensor selection
Thermocouple K (Default)
Thermocouple S
Thermocouple R
Thermocouple J
Thermocouple T
Thermocouple E
Thermocouple N
Thermocouple B
Pt100
Ni100
NTC 10kOhm
PTC 1kOhm
Pt500
Pt1000
0 to 10 V
0 to 20 mA
4 to 20 mA
0 to 60 mV
Pot. max. 6 kOhm
Pot. max. 150 kOhm
76
UA964801 - User manual
-260 °C to 1360 °C
-40 °C to 1760 °C
-40 °C to 1760 °C
-200 °C to 1200 °C
-260 °C to 400 °C
-260 °C to 1000 °C
-260 °C to 1280 °C
+80 °C to 1820 °C
-200 °C to 600 °C
-60 °C to 180 °C
-40 °C to 125 °C
-50 °C to 150 °C
-100 °C to 600 °C
-100 °C to 600 °C
