8.6

Totalizer function

The totalizer function, which can be enable by par. 9 Totalizer, performs an instant
measurement of the process and sums it on a time basis to the previously totalized
value.
Ex.: if a sensor 4 to 20mA with F.s. 9000m
select Hour on par. 9
considering the
8.7

Sum function

The sum function, which can be enabled by par. 10 Sum function, allows to increase
a counter adding the process value on command. It is an application typical for
weighing systems and allows to know the total weighed value.
Functions tare, sum and reset can be managed also by digital input if enabled on
par. 95 Digital Input 1 and par. 100 Digital Input 2.
Totalizer. The device will increase the totalized value
m flowing each second
3
On the dedicated page it is possible to
see the instant process value and the
totalized value: keeping pressed
possible to reset this value.
/hour is connected, it is necessary to
3
(2.5m ).
3
Press Sum Function
function page. Pressing
value is added to the counter. It is
possible to reset the total value keeping
pressed and to fix "tare zero" of the
Rst
process pressing
Rst
to enter the
the Process
+
Tar .
User manual - UA964801
it is
67
