11.2 V/I custom
Parameters to configure the customizable linear input.
17 V/I custom
Selects the linearization type for the analogue input if selected as linear.
Lower and
upper limits.
16 scaling points The input will be linearized by parameter 18-49
18 01-Input value
Defines the input value to which the 1st customized value is assigned
0 to 20000 Default: 0.
19 01-Custom value
Defines the 1st customized value assigned to the input
-32767 to +32767 [Digit
20 02-Input value
Defines the input value to which the 2nd customized value is assigned
0 to 20000 Default: 2000.
21 02-Custom value
Defines the 2nd customized value assigned to the input
-32767 to +32767 [Digit
22 03-Input value
Defines the input value to which the 3rd customized value is assigned
0 to 20000 Default: 0.
23 03-Custom value
Defines the 3rd customized value assigned to the input
-32767 to +32767 [Digit
80
UA964801 - User manual
The input will be linearized
by parameters 4 and 5 (Default)
] Default: 0.
2
] Default: 1000.
2
] Default: 0.
2
