Hardware Data; Software Data - PCE Instruments UA964801 Betriebshandbuch

4

Hardware data

Power supply
Analogue input
Relay outputs
Analogue output
4.1

Software data

Regulation
algorithms
Alarm mode
54
UA964801 - User manual
Extended power supply
24 to 230 Vac/Vdc ±15 %
50/60 Hz
AN1
Configurable via software.
Thermocouple type K, S,
R, J, T, E, N, B. Automatic
compensation of cold
junction from 0 to 50 °C.
Thermoresistance: PT100,
PT500, PT1000, Ni100, PTC1K,
NTC10K (β 3435K).
Input V/I (linear): 0 to 10 V,
0 to 20, 4 to 20 mA, 0 to 60 mV.
Potentiometer input: 6 KΩ,
150 KΩ.
2 Relays
1 tension
Linear 0 to 10 Volt.
1 current
Configurable as output
0 to 20 mA or 4 to 20 mA.
ON/OFF with hysteresis
Absolute / Threshold, Band with instantaneous/delayed/
retentive action/by digital input activation, Sensor failure /
Activation by serial line
Consumption: 6 VA.
Tolerance (25 °C)
+/-0.2% ±1 digit (F.s.) for
thermocouple, thermoresi-
stance and V / mA.
Cold junction accuracy 0.1
°C/°C.
Impedance:
0 to 10 V: Ri>110 KΩ
0 to 20 mA: Ri<5 Ω
4 to 20 mA: Ri<5 Ω
0 to 60 mV: Ri>1 MΩ
Contacts 2 A - 250 V~
Resistive charge.
All 16 bit +/-0.2 % (F.s.)
