8.2

Modifying alarm thresholds

Selecting one or more absolute/ band alarms, it is possible to modify the
intervention thresholds directly by the user menu, without entering configuration.
For the modification procedure refer to the following table:
Press
1
Sel
2
Sel
3
Sel
8.3

Latch on function

For the use with input Potentiometers max. 6 kohm and Pot. max. 150 kohm and
with linear input (0 to 10 V, 0 to 60 mV, 0/4 to 20 mA), it is possible to associate
the start value of the scale (par. 4 Lower limit V/I) to the minimum position of the
sensor and the value of end scale (par. 5 Upper limit V/I) to the maximum position
of the sensor.
64
UA964801 - User manual
Display
Selects the setpoint to be
modified.
Selects the next setpoint
(if active), otherwise go to
point 3.
and disappear
Press Setpoint
modification.
Press
the value. Pressing
possible to modify digit per
digit.
See point 1.
Press
to enter the thresholds
Do
and to modify
Esc to exit procedure.
it is
