11.8 Graphic

Parameters to configure the trend and bar graph management.
105 Graphic type
Selects the type of graph to be visualized on the relevant page.
Trend (Default)
Bar graph
106 Lower limit
Trend or bar graph lower limit.
-32767 to +32767 [Digit
107 Upper limit
Trend or bar graph upper limit.
-32767 to +32767 [Digit
108 Trend time
Selects the trend sampling time.
1 to 3600 seconds, Default: 60s.
109 Data logger
Enables the over time registration of the process in eeprom
The sampling time is equal to the trend upgrading time.
Disabled (Default)
Enabled

11.9 Analogue output in mA

Parameters to configure the analogue output in mA
112 Retransmission
Enables analogue output
Disabled (Default)
Process
92
UA964801 - User manual
], Default: 0.
2
], Default: 1000.
2
