Relay Q1 output
2A
230V
Q1
1/8Hp
Relay Q2 output
2A
230V
Q2
1/8Hp
mA / Volt output
AO1
0/4..20mA
AO2
0..10V
60
UA964801 - User manual
Capacity:
3
2 A / 250 V~ for resistive loads.
NB: see picture below
4
Capacity:
1
2A/250 V~ for resistive loads.
NB: see picture below
2
7
Pins 7-8: linear output in mA configurable using parameters
as retransmission of process or alarm setpoints (see par.
112-116).
8
8
Pins 8-9: linear output in Volt configurable using parameters
as retransmission of process or alarm setpoints (vedi par.
119-123).
9
Electrical endurance Q1 / Q2.
2 A, 250 Vac, resistive load, 10
20/2 A, 250 Vac, cosφ = 0.3, 10
operations.
5
operations.
5
