Flyer C SERIE Anleitung Seite 206

Move . the . joystick . left . or . right . to . switch . between .
the .individual .main .menus .on .the .display. .
The following main menus are available:
Drive: . Main .view .with .key .information .such .
as .speed, .remaining .range .etc. .The .
system .always .starts .up .in .this .view.
Info: . Information .about .the .current .journey
Fitness: .Information .about .the .rider's .athletic .
performance
Data: Topographic data and
ambient temperature
Navi: . Navigation .with .a .smartphone
1.
2.
3.
General vehicle settings
This display remains the same in all views and
shows you key settings and information on the
vehicle .and .the .current .journey. .
1. . Speed
2. . . Gear .recommendation .(only .with .(2-gear)
36V .Multi .Speed .mid-engine)
3. . . Current .motor .gear .(only .with .(2-gear)
36V .Multi .Speed .mid-engine)
4. . Light .(high/low .beam)
5. . Current assistance level
6. . Coloured .bars: . A ssist .power .indicator
Drive
1. . Current .speed
2. . Gear .recommendation .(only .with .(2-gear)
.
3. . Current .motor .gear .(only .with .(2-gear)
.
4. . Remaining .range/battery .level .based .on .the
4.
5. . Light .(high/low .beam)
6. . Current .assistance .level .
6.
7. . Time
8. . Current .screen . .top-centre .bar
5.
Info
1. . Charging .status .(top-left .symbol)
2. . Distance .travelled .on .current .tour .(trip)
3. . Average .speed .on .current .tour .(trip)
4. . Total .distance .travelled .(cannot .be .reset)
5. . Maximum .speed .on .current .tour .(trip)
6
8.
2.
3.
36V .Multi .Speed .mid-engine)
36V .Multi .Speed .mid-engine)
current assistance level (battery is red if
remaining range is below 20%)
1.
2.
4.
7.
1.
5.
4.
6.
4.
3.
5.
