The FLYER and its parts
29
6
7
1 Saddle
2 Seat post
3
Seat post clamp
4 Suspension rear fork/shock
5 Battery
6
Fork end
7 Rear derailleur
8 Chain
9
Electrical motor
10 Crank arm
11 Pedal
12
Pivot points/bearings
13 Frame
14 Stem
15
Handlebars with handle
16 Display
1
2
3
12
8
13
5
4
9
11
10
17 Shift lever
18 Brake lever
19
Brake cable/line
20 Shift cable
21 Headset
22
Suspension fork
23 Disc brake calliper
24 Brake disc
Wheel
25 Front hub
26
Spoke
27 Rim
28 Tyre
29
Valve
