ROSE BACKROAD Bedienungsanleitung Seite 12

3.2 In the box
3
2
4
1
1 Mudguard strut (2x)
2 Bolt M5x14 mm (2x)
3 Nut M5 (4x)
4 Left luggage rack strut
Right luggage rack strut
5 Bolt M5x20 mm (2x)
4
3
5
6
7
6 Rear wheel mudguard
7 Mounting clamp (2x)
8 Mudguard strut (2x)
9 Bolt M4x12 mm (2x)
10 Spacer washer 8x4.2x2 mm (2x)
11 Nut M4 (2x)
16
17
18
19
9
20
21
22
11 10
14
12 Mounting clamp (2x)
13 End cap (2x)
14 Front wheel mudguard
15 Fixing clip
16 Cover cap (7x)
17 Spacer washer 14x6.1x5 mm (4x)
18 Large washer (3x)
19 Spacer washer 14x6.1x2 mm
20 Spacer washer 8x5.2x5 mm (2x)
21 Small washer (9x)
22 Bolts (4x M5x12 mm, 1x M5x16 mm, 2x M5x20 mm, 2x M5x25 mm)
15
8
12 20
13
