Adjust the distance periodically to com-
pensate for wear on the grinding disc.
Mounting the device on a workbench
Tools required
(not included)
• Hex key (AF5)
• Ring spanner (AF10)
Accessories required
• Workbench‑Assembly materials (24):
• 4× Screw
• 4× Nut
• 8× Washer
Procedure (Fig. D)
1. Mount the device on a flat work surface.
2. Place a washer on each of the holes (11)
on the device base and insert the screws
from above through the holes.
3. Counter from below with the washers
and nuts.
4. Tighten the nuts.

Replacing the grinding disc

Information on replacement
• Never operate the tool without protective
equipment.
• Ensure that the rotation speed stated on
the grinding disc is the same or higher
than the nominal rotation speed of the
tool.
• Ensure that the grinding disc dimensions
match those of the tool.
• Only use grinding discs that are in perfect
condition (sound test: they have a clear
sound when struck with a plastic ham-
mer).
• Never re-drill a locating hole which is too
small for the grinding disc to make it lar-
ger.
• Never use separate bushings or adapters
in order to make grinding discs with a
hole that is too large fit the tool.
• Do not use saw blades.
• Only use the supplied clamping flanges
to clamp the grinding tools. The pads
between the clamping flange and grinding
tools must be made of elastic materials
e.g., rubber, soft cardboard etc.
• Always reassemble the tool completely
after replacing the grinding disc.
• Use protective gloves
• Switch off the tool and disconnect the
mains plug. Allow the tool to cool down.
26
Tools required
(not included)
• Phillips screwdriver
• Ring spanner (AF19) or open-end spanner
(AF19)
CAUTION! Risk of injury when
touching the attachment tool. Wear
protective gloves when handling the
attachment tool.
CAUTION! The grinding disc nut must not
be screwed too tight in order to prevent the
grinding disc and nut from breaking.
CAUTION! The grinding disc nuts have
different threads (left-hand and right-hand
threads). Never mix up the two nuts (26) to
avoid damaging the thread of the grinding
spindle (29).
Procedure (Fig. E/F)
1. Remove the spark guard (1) and work-
piece support (9).
2. Loosen the 3 screws (25) of the cover (6)
and remove the cover.
3. Unscrew the nut (26). Counter the grind-
ing disc (3/8) while doing so.
• Turn left-hand grinding disc nut (3) =
left-hand thread ⭮
• Turn right-hand grinding disc nut (8)
= right-hand thread ⭯
4. Remove the clamping flange (27), grind-
ing disc (3/8) and spacer (28).
5. Fit the new grinding disc (3/8), spacer
(28) and clamping flange (27).
6. Screw on the nut (26) by hand.
• Turn left-hand grinding disc nut (3) =
left-hand thread ⭯
• Turn right-hand grinding disc nut (8)
= right-hand thread ⭮
7. Tighten the nut (26) with a ring spanner
or open-end spanner by applying moder-
ate manual force.
8. Attach the cover (6).
9. Fit the spark guard (1) and workpiece
support (9) (see Attaching and adjusting
the spark guard, p. 25 and Attaching
and adjusting the workpiece support,
p. 25).
Trial run: Always carry out a trial run of at
least 1 minute duration without load before
carrying out your first grinding procedure
and after every grinding disc replacement.
Switch the tool off immediately if the grind-
