GB MT
• 2× Washer
• 2× Spring washer
• 2× Nut
• 2× Spark guard holder
• Assembly materials Spark guard holder:
• 2× Screw
• 2× Washer
• 2× Spring washer
• 2× Nut
• 2× Workpiece support
• Assembly materials Workpiece support:
• 2× Screw
• 2× Washer
• 2× Lock washer
• 2× Star grip nut
• Workbench‑Assembly materials:
• 4× Screw
• 8× Washer
• 4× Nut
• Translation of the original instructions

Overview

The illustrations for the device
can be found on the front and
back fold-out page.
1 Spark guard
2 Spark guard holder
3 Grinding disc A36 P5 V35
4 Guard cover (Grinding disc)
5 Gearbox housing
6 Cover (Grinding disc)
7 Power cord
Grinding disc A80 P5 V35
8
9 Workpiece support
10 Star grip nut (Workpiece support)
11 Hole (Workbench-Assembly)
12 On/Off switch
Fig. A
13 Screw
14 Washer
15 Spring washer
16 Nut
Fig. B
17 Screw
18 Spring washer
20
19 Washer
20 Nut
Fig. C
21 Screw
22 Washer
23 Lock washer
Fig. D
24 Workbench-Assembly materials
Fig. E/F
25 3× Screw
26 Nut
27 Clamping flange
28 Spacer
29 Grinding spindle

Description of functions

The double sander is a combination device
with two grinding discs with different grain
sizes for coarse and fine sanding.
The device features a guard cover and spark
guard.
Please refer to the descriptions below for in-
formation on how the operating elements
work.

Technical data

Double Bench Grinder .......... PDOS 200 C2
Rated voltage U ...................... 230 V∼, 50 Hz
Rated input power P ........... 200 W (S6 15 %)
No load power consumption P
Protection class ............................................ I
Protection type ....................................... IPX0
No-load rotation speed n
Weight with accessories ................. ≈ 6.45 kg
Sound pressure level (L
......................................... 85.2 dB; K
Sound power level (L
WA
Operating mode S6 15 %: Continuous oper-
ation with intermittent load.
After an uninterrupted operating time of
1½ minute under load, the tool must then
cool down for 8½ minutes in idle mode,
otherwise overheating would occur.
Operating mode S1: Continuous operation
with constant load
... 145 W (S1)
0
−1
........≈ 2980 min
0
)
pA
=3 dB
pA
) 98.2 dB; K =3 dB
WA
