Installation
Table continued from last page
Phase
1 Phase
(1, 2 and 3
interconnected)
NOTE!
Setting a lower value of the power limiter parameter will cause a reduced performance of the
induction hob.
See the connection diagrams for the voltage between the phase and neutral conductors and voltage
between the phase conductors.
Power cord core cross sectional area should be at least 1,5 mm² for the following power limiter
settings which should be adjusted to your circuit breakers:
Power limiter
configuration
3x16 A / 3x13 A /
3x10 A / 3x06 A
2x16 A / 2x13 A /
2x10 A / 2x06 A
2 x 16 A
3 x 16 A
2 x 32 A
1x32 A / 1x25 A
1x20 A
1x16 A
48
IMax (A) Grilling Frying
40 x x
35 x x
32 x x
25 x x
20 x x
16 x x
13 x x
10 - -
6 - -
Connection type
3 phases - 1 neutral
2 phases - 1 neutral
2 phases - 2 neutral (only for NL)
3 phases (only for BE)
2 phases - 1 neutral
1 phase - 1 neutral
1 phase - 1 neutral
1 phase - 1 neutral
Boiling Simmer
x x
x x
x x
x x
x x
x x
- x
- x
- x
Power cord
Type
H05V2V2-F
H05V2V2-F
H05V2V2-F
H05V2V2-F
H05V2V2-F
H05V2V2-F
H05V2V2-F
H05V2V2-F
Keep warm Melting
x x
x x
x x
x x
x x
x x
x x
x x
x x
Number and cross
section of Power cord
wires
5 x 1.5 mm²
4 x 1.5 mm²
5 x 1.5 mm²
4 x 1.5 mm²
4 x 4.0 mm²
3 x 4.0 mm²
3 x 2.5 mm²
3 x 1.5 mm²
