The hob is fitted with a fan located in its lower part. If there is a drawer underneath the countertop,
do not use it to store small objects or paper as these could, if sucked into the fan, damage the fan
and the cooling system. Moreover, do not use the drawer to store aluminium foil or flammable
substances or liquids (such as sprays). Keep such substances away from the cooking hob. Danger of
explosion! There should be at least 20 mm of clearance between the contents of the drawer and the
fan inlet vents.

Flush-mount

The appliance may only be installed into a temperature- and water-resistant countertop, such as a
countertop made of (natural) stone (marble, granite), or solid wood (the edges along the cut-out
have to be sealed). When installing into a countertop made of ceramics, wood, or glass, a wooden
sub-frame should be used. The frame is not supplied with the appliance. The appliance may only
be installed into a countertop made of other materials after you have consulted the countertop
manufacturer and obtained his express approval. Internal dimension of the basic unit should be at
least equal to the internal cutout for the appliance. This will allow simple removal of the appliance
from the countertop. Attach sealing tape along the perimeter of the bottom of the glass panel.
Install the appliance (see 'Installation') and connect the appliance to the mains power supply (see
instructions for connecting the appliance). Test the operation of the appliance before applying the
seal. Seal the groove between the appliance and the kitchen worktop with a silicone sealant.
The silicone sealant used to seal the appliance must be temperature-resistant (to at least 160 °C).
Smooth out the silicone sealant using suitable tools. Observe the instructions for use of the selected
silicone sealant. Do not switch on the appliance until the silicone sealant has dried completely.
1. Silicone sealant, 2. Sealing tape
Lower cabinet with an oven
Only install ovens with a cooling fan under
the induction hob. Before installing the
oven, the kitchen cabinet rear wall has to
be removed in the area of the opening for
installation.
If other appliances are installed under the
induction cooking hob, we cannot
guarantee their correct operation.
