EN
without the aid of tools.
- Connect the high pressure hose to the gun.
- Turn the water tap fully on. The water temperature
absolutely must be below 40°C.
IMPORTANT: The washer machine has to
operate with clean water in order to avoid any
damages to the washer machine itself.
- Release the gun safety catch and keep the trigger
pressed, allowing the water to flow until all the air
has been expelled.
- Fit the lance into the gun.
- Connect the plug to the power socket.
- To start the machine, press the gun trigger and at
the same time turn the master switch to "ON".
> FILLING UP
Fill up the tank with the fuel indicated on the
technical data plate.
Avoid that the tank is empty when the machine is
running in order not to damage the fuel pump.
WARNING:
•
they as provide hazard.
Fill up the detergent tank with the suggested
products, suitable for the kind of washing to be
carried out .
WARNING:
• make use only of liquid detergent,
do not absolutely use acid or too much alkaline
products.
We suggest you to make use of our products,
which have been studied for the use with washer
machines.
> STARTING UP
See fig.
Start the machine:
turn the 2 switch to pos. ( I ) ON .
MOD. : XTR-R
To wash with hot water:
turn the 1 burner switch to pos. ( I ) ON .
The burner operates when the machine is in
pression.
MOD. : RIO-R; RIO-R PRO
To wash with hot water:
22
Incorrect fuel shall not used as
turn the burner switch 1 and select the desired
temperature setting.
The burner operates when the machine is in
pression.
> HIGH PRESSURE LANCE
See fig.
> DETERGENT SUCTION
See fig.
> HIGH PRESSURE HOSE
See fig.
> WATER SUPPLY
Water supply collection
Water supply from the water main
- Connect a supply hose (not included) to the
water inlet of the unit and to the water supply.
- Open the water supply.
WARNING:
suitable for connection to the potable
water mains.
The cleaner can only be connected to the water
mains if the water mains is separated by a backflow
preventer. Make sure that the hose is at least Ø
13mm-1/2 inch and that it is reinforced.
WARNING:
•
Water that has flown through
backflow preventers is considered to be
nonpotable.
IMPORTANT: Only clean or filtered water should
be used for intake. The delivery of the water
intake tap should be equal to the double of the
maximum pump range.
Minimum delivery rate: 15 l/ min.
Maximum intake water temperature: 40°C
Max inlet water pressure: 1Mpa
Place the cleaner as close to the water supply system
as possible.
Water supply from an open container
- Unscrew the coupling part for the water inlet.
(symbol) machine not
