Westermann Cleanmeleon 2 PRO Betriebsanleitung Seite 200

20
Spare parts overview
4 Flange bearing
5 Mudguard washer
6 Hexagon nut
7 Chain guide disc
8 Disc
9 Liner
10 Rear swinging fork
11 Hexagon head screw
12 Tyres
13 Adjusting collar
14 Spacer bushing
15 Rear axle
16 Hexagon head screw
17 Self-locking nut
18 Round-head bolt
19 Hexagon head screw with flange
88
KT-00-00113
DIN-9021-13,0
DIN-985-M10
LA-00-00314
DIN-125-10,5
KT-00-00101
LA-00-01219
DIN-933-M10x40
RE-00-00019
KT-00-00407
DR-00-00154
DE-00-00155
DIN-933-M10x50
DIN-SZ-M10
DIN-603-M10x25
DIN-6921-M10x20
1
1
1
2
24
4
1
2
1
2
2
1
2
4
4
2
