Westermann Cleanmeleon 2 PRO Betriebsanleitung Seite 198

20
Spare parts overview
Exhaust
20.5.2
Pos. Designation
1 Hexagon head screw
2 Hexagon head screw with flange
3 Hexagon head screw with flange
4 Self-locking nut
5 Exhaust retaining plate
6 Spacer tube
7 Disc
8 Rear exhaust cover
9 General purpose kit
10 Top/bottom exhaust cover
11 Front exhaust cover
12 Cap nut
86
Fig. 47: Exhaust spare parts
Item no.
DIN-931-M8x145
DIN-6921-M6x16
DIN-6921-M8x20
DIN-SZ-M8
LA-00-00739
DR-00-00033
DIN-125-8,4
LA-00-00193
KT-00-00182
LA-00-00194
LA-00-00195
DIN-1587-M8
Quantity
4
4
2
2
1
1
2
1
1
2
1
4
