Operation
9 Operation
The machine is operated exclusively via the control units on the steering column. The
lifting gear is operated via a control block valve with hand lever control. For moving
forward and in reverse, as well as for the handling sequences, the operator uses a
continuously variable foot pedal and the steering wheel with a steering angle of
88 degrees.
9.1 Control elements
Pos. Designation
1 Directional valve
2 Hydraulic plug-in coupling
3 Parking brake
4 Accelerator pedal
5 Rotating speed regulation
5 Choke
Ignition key
28
Fig. 7: Control elements
Function
Hydraulic control for the power lift incl. control
circuit
Plug-in couplings for the hydraulic circuit of the
attachment
Secures the machine against uncontrolled rolling
away
Accelerator pedal for continuously variable
speed regulation and for determining the
direction of travel
Regulation of the engine speed
Cold start aid
Starting/stopping the engine
