20
Spare parts overview
Frame connection and gearbox disengagement
20.3.2
Fig. 41: Frame connection and gearbox disengagement spare parts
Pos. Designation
1 Pressure spring
2 Disc
3 Hexagon nut
4 Freewheel gearbox
5 Disc
6 Hexagon head screw with flange
7 Front axle mounting bracket
8 Hexagon head screw
9 Self-locking nut
Item no.
KT-00-00679
DIN-9021-8,4
DIN-985-M8
LA-00-01242
DIN-125-8,4
DIN-6921-M8x20
LA-00-01224
DIN-933-M8x75
DIN-SZ-M8
Quantity
1
4
8
1
14
4
2
8
4
79
