11
Operation
11.5 Function overview
Fig. 14: Seat adjustment
Fig. 15: Parking brake
Fig. 16: Gearbox disengagement
Seat adjustment
The lever for the seat adjustment (for optimum
positioning on the machine) is located under the seat
on the left in the direction of travel.
The seat adjustment is unlocked by briefly pulling the
lever outwards. Positioning takes place via body
movement.
Parking brake
To prevent the machine from leaving its position when
at rest, the parking brake can be applied for safety
reasons.
To apply the handbrake, pull the brake lever on the
steering column upwards and place it in the notch.
Gearbox disengagement
If the CM2 PRO is to be moved manually, the gearbox
disengagement must be used.
To operate the gearbox disengagement, remove the
rubber blanket and move the lever shown.
Only disengage the gearbox when the engine is
switched off!
Activating the disengagement
- Press the lever at the foremost tip
Disengaged position
5 cm) down to get over the nut.
Driving position
- Pull the lever forwards and release above pos.
- Gearbox disengaged.
Guide slot incl.
compression spring
Deactivating the disengagement
to secure position
- Press the lever
- Then release the lever above pos.
- Gearbox disengagement deactivated.

down and push backwards.

.

(approx. 2 –
.

35
