8 Connection preparations
8.2 Hybrid cable assembly for the box with N/U design
The following must be observed when using other ferrules:
● Choose ferrules that are suitable for the core cross section.
● Check core lengths and adjust if necessary.
● Strip insulation and connect the cores according to the data sheet.
Assembly for:
● BZK␣␣S0N␣␣L
● GEL 6109CO␣␣␣␣␣xxM03
● GEL 611␣CO␣␣␣␣␣xx0␣3
Minimum bending radius of the hybrid cable: 95 mm
Assembly for:
● BZK␣␣S0U␣␣L
● GEL 6109CO␣␣␣␣␣xxM13
● GEL 611␣CO␣␣␣␣␣xx1␣3
Minimum bending radius of the hybrid cable: 142.5 mm
8.2.1 Preparing the hybrid cable
Accessories und tools
Tools
● Sheath stripping tool
● Side cutter
● Wire stripping tool
● Crimping tool
● Hot air gun
Connection accessories: Power supply positioning drives
● 2 ferrules with plastic sleeve, size 0.5 mm
● 2 ferrules with plastic sleeve, size 1.5 mm
Connection accessories: Internal communication positioning drives
● 1 ferrule with plastic sleeve, size 0.14 mm
● 2 ferrules with plastic sleeve, size 0.25 mm
General accessories (part of the accessories set, item number 89070 or ZB6505UL01)
● 60 mm heatshrink sleeve Ø 13 mm, item number: LZ1225
● 25 mm heatshrink sleeve Ø 6 mm, item number: LZ1231
124
Hybrid cable assembly box (N/U design)
2
× 10 mm
2
× 12 mm
2
× 8 mm
2
× 8 mm
