Inbetriebnahme in Verbindung mit IO-Link
ISDU Name
1)
Index
hex. dez.
0x487 1159 Startup
0x488 1160 Rated power
0x489 1161 Rated voltage
0x48A 1162 Rated frequency
0x48B 1163 Rated speed
0x48C 1164 Nominal motor current R
0x48D 1165 Cosine Phi
0x48E 1166 Premagnetization time R
1) Subindex = 0
2) Von Data Storage ausgeschlossen
IO-Link-Parameterverzeichnis MOVIFIT
ISDU Name
Index
hex. dez.
0x3E9 1001 Start mode drive 1
0x3EA 1002 Start mode drive 2
0x3EB 1003 Rated motor current 1 R/W
0x3EC 1004 Rated motor current 2 R/W
0x3ED 1005 Soft startup time drive
1
0x3EE 1006 Soft startup time drive
2
0x3EF 1007 Braking time drive 1
0x3F0 1008 Braking time drive 2
80
Betriebsanleitung – MOVIFIT
Zugriff
R: Read
W: Write
R
R
R
R
R
R
®
compact-Starter
Zugriff
R: Read
W: Write
R/W
R/W
R/W
R/W
R/W
R/W
®
compact
Datentyp Werte/Wertebereich
Anmerkungen
32-Bit- 0 = Easy
UInteger
1 = Pro
32-Bit- 0, 90 – 3000
UInteger
32-Bit- 0, 20000 – 700000
UInteger
32-Bit- 0, 10000 – 500000
UInteger
32-Bit- 0, 10000 – 6000000
UInteger
32-Bit- 0, 100 – 300000
UInteger
32-Bit- 0, 500 – 950
UInteger
32-Bit- 0 – 2000
UInteger
Datentyp Werte/Wertebereich
Anmerkungen
32-Bit- 0 = Voltage Limiting
UInteger
1 = Current limiting
32-Bit- 0 = Voltage Limiting
UInteger
1 = Current limiting
32-Bit- 100 – 10000
UInteger
32-Bit- 100 – 10000
UInteger
32-Bit- 0 – 2000
UInteger
32-Bit- 0 – 2000
UInteger
32-Bit- 0 – 2000
UInteger
32-Bit- 0 – 2000
UInteger
®
MOVILINK
Index
Subindex
10546.159
10546.160
10546.160
10546.160
10546.160
10546.160
10546.160
10546.160
®
MOVILINK
Index
Subindex
10546.201
10546.202
8648.0
8649.0
10096.1
10096.2
10546.207
10546.208
