Elektrische Installation
5
Installationsvorschriften
5.4.7 UL-gerechte Installation
Field Wiring Power Terminals
Short Circuit Current Ratings
30
Betriebsanleitung – MOVIFIT
HINWEIS
Folgendes Kapitel wird unabhängig von der Sprache dieser Dokumentation aufgrund
von UL-Anforderungen immer in englischer und französischer Sprache abgedruckt.
Use 60/75 °C fine stranded copper wire only sized AWG 14 – 10, suitable for 1 wire
per terminal.
Suitable for use on a circuit capable of delivering not more than 10,000 rms symmetri-
cal amperes when protected as follows:
All models are rated 10 kA when protected as follows:
• 500 V minimum, 20 A maximum, non-semiconductor fuses or
• 500 V minimum, 20 A maximum, inverse time circuit breakers with an interrupting
rating not less than 10,000 rms symmetrical amperes.
®
• MOVIFIT compact MBF only: Combination Motor Controller Model MS132-2.5,
manufactured by ABB Rated 500 V, 2.5 A
The max. voltage is limited to 500 V.
Suitable for motor group installation on a circuit capable of delivering not more than
10,000 rms symmetrical amperes when protected as follows:
All models are rated 10 kA for group installation when protected as follows:
• 500 V minimum, 20 A maximum, non-semiconductor fuses or
• 500 V minimum, 20 A maximum inverse time circuit breakers with an interrupting
rating not less than 10,000 rms symmetrical amperes.
The max. voltage is limited to 500 V.
®
