ISDU Name
1)
Index
hex. dez.
0x3ED 1005 Premagnetization time R/W
0x3F3 1011 Nominal motor current R/W
0x3F5 1013 Rated power
0x3F6 1014 Rated voltage
0x3FD 1021 Ramp t11 up
0x3FF 1023 Boost
0x401 1025 Output Current
0x402 1026 DC link voltage
0x403 1027 Basic unit firmware
0x405 1029 Heat sink temperature R
0x409 1033 Output Current %
0x40A 1034 Current limit
0x40E 1038 UL motor current
weighting factor
0x40F 1039 Cosine Phi
0x410 1040 PWM frequency
0x411 1041 Startup
0x412 1042 Operating mode
0x413 1043 Commence startup
0x415 1045 Ramp t11 down
Inbetriebnahme in Verbindung mit IO-Link
Zugriff Datentyp Werte/Wertebereich
R: Read Anmerkungen
W: Write
32-Bit- 0 – 2000
UInteger
32-Bit- 100 – 300000
UInteger
R/W 32-Bit- 90 – 3000
UInteger
R/W 32-Bit- 20000 – 700000
UInteger
R/W 32-Bit- 125 – 1500000
UInteger
R/W 32-Bit- 0 – 50000
UInteger
R 32-Bit- -2147483648 –
UInteger 2147483647
R 32-Bit- 0 – 4294967295
UInteger
R 32-Bit- 0 – 4294967295
UInteger
32-Bit- -2147483648 –
UInteger 2147483647
R 32-Bit- 0 – 4294967295
UInteger
R/W 32-Bit- 0 – 150000
UInteger
R/W 32-Bit- 0 – 100000
UInteger
R/W 32-Bit- 500 – 950
UInteger
R/W 32-Bit- 4 = 4 kHz
UInteger
16 = 16 kHz
R/W 32-Bit- 0 = Easy
UInteger
1 = Pro
R/W 32-Bit- 0 = Vf
UInteger
1 = LVFC
R/W 32-Bit- 0 = Ready
UInteger
1 = Start
2 = Finished
R/W 32-Bit- 125 – 1500000
UInteger
Inbetriebnahme
MOVILINK
Index
Subindex
8526.0
8648.0
10546.13
8652.0
8807.0
10546.23
8326.0
8325.0
10546.27
8327.0
8321.0
8516.0
10546.38
8674.0
10546.40
10546.41
10546.42
10546.43
8808.0
