RIA452
Function (menu item)
Width
Kha-Venturi
ISO Venturi
BST Venturi
Parshall
Palmer-Bow.
Rect.WTO
Endress+Hauser
Parameter setting
9999
QV 302
QV 303
QV 304
QV 305
QV 306
QV 308
QV 310
QV 313
QV 316
415
425
430
440
450
480
4"
7"
12"
18"
30"
1"
2"
3"
6"
9"
1 ft
1.5 ft
2 ft
3 ft
4 ft
5 ft
6 ft
8 ft
6"
8"
10"
12"
15"
18"
21"
24"
27"
30"
5H
T5
Description
Value for width. Can only be selected for channel types marked with (w) (see
Flumes-Weir)
Khafagi-Ven-
turi channels
QV 302 = Khafagi-Venturi channel QV 302
QV 303 = Khafagi-Venturi channel QV 303
QV 304 = Khafagi-Venturi channel QV 304
QV 305 = Khafagi-Venturi channel QV 305
QV 306 = Khafagi-Venturi channel QV 306
QV 308 = Khafagi-Venturi channel QV 308
QV 310 = Khafagi-Venturi channel QV 310
QV 313 = Khafagi-Venturi channel QV 313
QV 316 = Khafagi-Venturi channel QV 316
ISO-Venturi channels
415 = ISO-Venturi channel 415
425 = ISO-Venturi channel 425
430 = ISO-Venturi channel 430
440 = ISO-Venturi channel 440
450 = ISO-Venturi channel 450
480 = ISO-Venturi channel 480
Venturi channels as per British Standard
4" = Venturi channel as per British Standard 4 inch
7" = Venturi channel as per British Standard 7 inch
12" = Venturi channel as per British Standard 12 inch
18" = Venturi channel as per British Standard 18 inch
30" = Venturi channel as per British Standard 30 inch
Parshall channels
1" = Parshall channel 1 inch
2" = Parshall channel 2 inch
3" = Parshall channel 3 inch
6" = Parshall channel 6 inch
9" = Parshall channel 9 inch
1 ft = Parshall channel 1 ft
1.5 ft = Parshall channel 1.5 ft
2 ft = Parshall channel 2 ft
3 ft = Parshall channel 3 ft
4 ft = Parshall channel 4 ft
5 ft = Parshall channel 5 ft
6 ft = Parshall channel 6 ft
8 ft = Parshall channel 8 ft
Palmer-Bowlus channels
6" = Palmer-Bowlus channel 6 inch
8" = Palmer-Bowlus channel 8 inch
10" = Palmer-Bowlus channel 10 inch
12" = Palmer-Bowlus channel 12 inch
15" = Palmer-Bowlus channel 15 inch
18" = Palmer-Bowlus channel 18 inch
21" = Palmer-Bowlus channel 21 inch
24" = Palmer-Bowlus channel 24 inch
27" = Palmer-Bowlus channel 27 inch
30" = Palmer-Bowlus channel 30 inch
Rectangular weir
5H = rectangular weir WTO/5H
T5= rectangular weir WTO/T5
Commissioning
91
