20
VOCODER VC16
HIDDEN FUNCTIONS
CALIBRATION
The Vocoder VC16 comes calibrated from the factory. Should
it become necessary to re-calibrate please follow these
instructions:
•
Disconnect all CV inputs except v/oct, which should
be connected to a well calibrated CV keyboard or
MIDI/CV converter.
•
Press the Carrier Bank 1 and 2 buttons simultaneously,
the first LED will flash green.
•
Send 1 V to the v/oct input from the keyboard.
•
Press any button, the first LED will now flash yellow.
•
Send 3 V to the v/oct input from the keyboard.
•
Press any button, the Vocoder VC16 will now
leave calibration mode.
MIDI CHANNEL SELECT
To select the MIDI channel that the Vocoder VC16 will respond
to press and hold the Carrier Bank 1 button (1) and use the
Carrier Shape control (3) to scroll through the channels.
The display will show you which channel has been selected:
Yellow LED
1
4
2
5
3
6
Green LED
10
7
8
11
9
12
Red LED
13
16
14
11
15
12
Release the Carrier Bank 1 button to return to
normal operation.
21
Quick Start Guide
