Specifications
Carriers
Buttons Carrier Bank 1, Carrier Bank 2
Carrier Shape, Formant, Envelope
Controls Sensitivity, Carrier Shape CV attenuverter,
Carrier In attenuverter
Carrier Shape CV (3.5 mm TS jack, range
-5 V to +5 V, 100 kΩ impedance)
Carrier In (3.5 mm TS jack,
100 kΩ impedance)
Carrier In (3.5 mm TS jack,
Inputs
100 kΩ impedance)
CV In (3.5 mm TS jack,
range -3 V to +7 V, 100 kΩ impedance)
Gate In In (3.5 mm TS jack,
range -3 V to +7 V, 100 kΩ impedance)
Modulator
Controls Input level
Combined XLR/6.35 mm (1/4") TS
Inputs
unbalanced jack (100 kΩ impedance)
Frequency Modulation
Controls FM In attenuverter
FM In In (3.5 mm TS jack, range -8 V to +8
Inputs
V, 100 kΩ impedance)
MIDI
Inputs MIDI In (5 pin DIN)
USB
Inputs USB Type C
Output
Audio Out (3.5 mm TS jack, 100 kΩ impedance)
Power Requirements
Current Draw 100 mA
Eurorack
(+12 V) / 20 mA (-12 V)
Physical
Dimensions 80.96 x 52.8 x 128.5 mm
(W x H x D) (3.19 x 2.09 x 5.06")
Eurorack
16 hp
units
Weight 167.5 g (5.91 oz)
