8.5
Select adapter (18/19/20/21/22) for
the compressed air hose (15)
(Fig. 5)
Select the appropriate adapter (15a/18/19/20/21/22a) for
the work to be carried out:
• Valve adapter (15a):
The valve adapter can be attached directly to valves
for car and motorcycle tyres for inflation.
• Small and large valve adapter (18/19):
The small and large valve adapters are conical in
shape and are used for valves without a screw thread,
such as those found on inflatable airbeds, swimming
rings and other leisure articles.
• Ball needle (20):
The ball needle is a long, thin adapter for inflating
sports balls such as footballs, basketballs or volley-
balls.
• Bicycle valve (21):
The bicycle valve is suitable for inflating common bicy-
cle tyres.
• Connecting piece (22) and adapter nozzles (22a):
This set allows you to quickly switch between different
nozzles for different applications. The adapter nozzles
are used, for example, for air mattresses, boats and
similar objects.
8.6
Inserting/removing the adapter
(18/19/20/21/22/22a) (Figs. 2, 5)
• Select the appropriate adapter (18/19/20/21/22/22a)
for the work to be performed (see 8.5).
• To use the small and large conical valve adapters
(18/19), the ball needle (20), the bicycle valve (21) or
the connecting piece (22) with the adapter nozzles
(22a), connect the compressed air hose (14) to the
tyre pressure gauge (12) as described in 8.3.
• The extension adapter (17) can only be used directly
on the tyre pressure gauge (12).
Connect:
Small and large conical valve adapter (18/19) / ball
needle (20) / bicycle valve (21) / connection piece (22):
1. Press the lever on the valve adapter (15a) and hold it.
2. Insert the appropriate adapter (18/19/20/21/22) into
the valve adapter (15a).
3. Release the lever on the valve adapter (15a).
Adapter nozzles (22a):
1. Screw the adapter nozzle (22) that is suitable for you
onto the connecting piece (22).
Remove:
Adapter nozzles (22a):
1. Unscrew the adapter nozzle (22a) from the connection
piece (22).
Small and large conical valve adapter (18/19) / ball
needle (20) / bicycle valve (21) / connection piece (22):
1. Press the lever on the valve adapter (15a) and hold it.
2. Pull the adapter (18/19/20/21/22) forwards out of the
valve adapter (15a).
3. Release the lever on the valve adapter (15a).
22 | GB
8.7
Inserting/removing the battery (16)
in the battery mount (2) (Fig. 6)
CAUTION
Danger of injury!
Do not insert the battery until the battery-powered tool
is ready for use.
Inserting the battery
1. Slide the batteries (16) into the battery mounts (2).
The batteries (16) click into place audibly.
Removing the battery
1. Press the unlock button (16a) of the batteries (16) and
remove the batteries (16) from the battery mount (2).
9
Operation
CAUTION
Danger of injury!
Do not insert the battery until the battery-powered tool
is ready for use.
ATTENTION
Wear hearing protection!
Use suitable hearing protection when you are near the
device.
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
Note:
• The product vibrates during operation. Therefore,
place it on a firm and level surface during operation.
The greatest inclination from the horizontal is 10º.
There are four feet on the underside of the product for
this purpose.
• Ensure that all hoses and fixtures are suitable for the
maximum permissible working pressure of the com-
pressor.
9.1
Switching the product on/off
(Fig. 7)
Switching on
1. Switch the product on by setting the on/off switch (3)
to the "I" position.
The product starts as soon as the vessel pressure falls
below the set operating pressure.
Switching off
1. Switch the product off by setting the on/off switch (3)
to the "0" position.
www.scheppach.com
